1. Description
This paper corner board machine adopts PLC control system, use servo motor for cutting device, Max. speed can reach 40m/min. The forming section has 7 units wheels with drive, and the left 2 units are driven, this makes the protector very strong and beautiful.
2. Specification
|
Model |
EMMXUVF150 |
|
V protector wing size |
25mm—100mm |
|
Quantity of layers |
Max. 13 layers |
|
Min. cutting length |
100mm |
|
Length of the final product |
100--4500mm |
|
Production speed |
0-40m/min |
|
Heating method |
Electrical |
|
Cutting method: |
Servo motor |
|
Motor power |
10KW(Not include heating device) |
|
Total Weight |
App. 4.5T |
|
Overall size |
23000mm(L)×980mm(W)×1600mm(H) |
|
Tolerance |
±1mm |
|
Forming device |
7 units wheels with drive, 2 units driven |
